Pentair IntelliFlo VS+SVRS Variable Speed Plus Safety Vacuum Release System Pool Pump 011057
Pentair IntelliFlo VS+SVRS Variable Speed Plus Safety Vacuum Release System Pool Pump 011057
Pentair IntelliFlo VS+SVRS Variable Speed Plus Safety Vacuum Release System Pool Pump 011057
Pentair IntelliFlo VS+SVRS Variable Speed Plus Safety Vacuum Release System Pool Pump 011057
Pentair

Pentair IntelliFlo VS+SVRS Variable Speed Plus Safety Vacuum Release System Pool Pump 011057

SKU: 011057
Regular price $2,199.00 $0.00 Unit price per
Shipping calculated at checkout.

The IntelliFlo VS+SVRS Variable Speed Pump was the first pump developed with an integrated Safety Vacuum Release System (SVRS). This system features a built-in controller and proprietary software designed to help detect a suction or drain blockage and automatically stop the pump to provide an added layer of protection against entrapment. The IntelliFlo VS+SVRS pump complies with the current ASME A112.19.17 standard for Safety Vacuum Release Systems (SVRS)
Ā
Designed to pair with Pentair Easy Touch or IntelliTouch Automation Systems, the IntelliFlo VS+SVRS can be programmed to deliver the right flow required for filtration, water features, spas and other equipment. With the IntelliFlo VS+SVRS, you can add equipment and features, or change them, without reducing pump performance all while still providing maximum energy efficiency.
Ā
Features
  • Proprietary software designed to help detect a suction or drain blockage, automatically stopping the pump
  • Compliant with the current ASME A112.19.17 standard for Safety Vacuum Release Systems (SVRS)
  • Eight (8) programmable speed settings and built-in timer
  • New rotatable keypadĀ for easy programming and viewing - keypad has the ability to be wall mounted with optional wall mount kit (sold separately)
  • Intuitive interface/ HMI simplifies programming and use
  • Top-mounted field wiring compartment for easy access and installation
  • Totally-enclosed fan-cooled design (TEFC) for quiet operation
  • Built-in diagnostics protect the pump for longer service life
  • Interfaces perfectly with Pentair automation systems
  • ENERGY STAR Certified
Standard for residential and commercial swimming pool, spa, hot tub and wading pool suction systems, as required by the Virginia Graeme baker pool and spa safety act.
Ā
Optional keypad wall mount kit part No. 356904Z
Ā
The ONLY Way To Comply With New Federal Anti-Body Entrapment Standards And Save Money
Ā
There's simply no better way to add a Safety Vacuum Release System (SVRS) to your public pool or spa than with the IntelliFlo VS+SVRS pump. It helps prevent suction entrapment and also provides value that no other solution can. While other safety solutions represent an added cost, the IntelliFlo VS+SVRS pump is an investment that may potentially save thousands of dollars in energy costs over its long life.
Ā
Safety Features
  • Includes a built-in controller with proprietary software that detects blockage and automatically shuts itself off within seconds
  • Meets ASME A112.19.17.2002 standards, thus complying with the Virginia Graeme Baker Pool Safety Act SVRS Requirements
  • No SVRS calibration required: the blockage detection/shut down function is pre-programmed into the software
  • Unlike other devices, the IntelliFlo VS+SVRS pumpā€™s SVRS protection cannot be turned off
  • For added safety, if the SVRS becomes disabled, the pump will not run
  • Safety lock-out feature (password protected) prevents pump speed settings from being changed by unauthorized personnel
Why slower is better
Ā
The surprising secret to minimizing pump energy costs is to operate at the lowest speed needed to accomplish a job. It takes far less energy to move water slowly than quickly. Why? Because thereā€™s lower resistance in the filter, accessories and plumbing system. Even with only modest pump speed reductions, the effect on electricity usage can be dramatic. In fact, reducing pump motor speed by 25% actually reduces the power needed by 58% of whatā€™s consumed at the higher speed. A good analogy is your car: you get much better gas mileage at 30 mph than at 90 mph. The same is true with pool pumpsā€”run slower to reduce energy used.
Ā
Ā
Engineered for exceptionally long life
Ā
The IntelliFloĀ® VS+SVRS Pumpā€™s permanent magnet motor produces far less heat and vibration than traditional induction motors. This not only results in less stress and wear on pump components, but on other equipment, too. Exclusive load-sensing software provides nearly instant priming which saves energy and reduces wear and tear on the pump. Plus, built-in diagnostics protect the IntelliFlo VS+SVRS pump from the most common causes of premature pump failureā€”loss of prime, overheating, freezing and voltage irregularities. The result is you can expect dramatically longer life and an even greater return on your investment.
Ā
Other Features
Ā
The IntelliFlo VS+SVRS pump anticipates and solves other pool operating challenges:
  • Easy to program and monitor: simple push-button controls and clear LCD readouts make operation a cinch
  • Ability to set minimum and maximum speeds: The IntelliFlo VS+SVRS pump will only operate within the ranges you set to help assure safer operation and long equipment life
  • Built-in clock and timer: eliminates the need for an added time clock or expensive controller
